F-29-(OPTIONAL)
HeroXPULSE 2004V DAKAR EDITION(Jan.,2025) · 9 parts
Parts in This Assembly (9)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 57111-ABW-L00 | HECU MINI MAB | 1 | |
| 2 | 53100-ABW-L200 | PIPE STRG HANDLE | 4 | |
| 3 | 31500-KRY-801 | BATTERY ASSY MF7 | 2 | |
| 4 | 99670-AAE-300 | BUNGEE NET | 1 | |
| 5 | 9945ABWL00S | PREMIUM MOBILE HOLDER | 1 | |
| 6 | 50803-ABW-B00 | GUARD ENGINE R | 1 | |
| 7 | 50804-ABW-B00 | GUARD ENGINE L | 1 | |
| 8 | 77200-ABW-110 | SEAT COMP DOUBLE | 1 | |
| 9 | 90113-ABW-L00 | BOLT SPECIAL HEX 6X16 | 1 |
